Seiko LSC-8BV-2 Cylinder Arm with Binder

Call for Price

Seiko LSC-8BV-2

Seiko LSC Series Industrial Walking Foot Cylinder Arm with Synchronize binder Sewing Machine.

Model Seiko LSC-8BV-2: High Speed, Single Needle, Compound Feed and Walking Foot, Narrow Cylinder Arm, with synchronized binder Lockstitch Sewing Machine, with reverse.

This machine has been a proven capable stable heavy-duty cylinder armbinder sewing machine for years.

Applications:

For sewing medium to heavyweight materials such as leather, vinyl, synthetics and laminated and coated materials

Suitable for sewing all tubular & cylindrical work that needs tape/binding attached. Such as filtration products hat mfc bags boots orthopaedic work.

. Model Seiko LSC-8BV-2:

Features:

· Semi-automatic lubrication system.

· Standard horizontal axis hook and base.

· Synchronized Binder mounting plate moves the binder in time with the feed & walking foot.

· Reverse stitching.

· Special designed narrow cylinder arm at only 46mm diameter.

· Synchronized binder

  • Automatic Foot lift & Automatic Backtack available.

Other models available

LSC-8B-2: Standard hook
LSC-8BV-2:  Standard hook, synchronized binder
LSC-8BLV-1: Large hook, synchronized binder
LSC-8BLH-1: Large hook, horizontal feed
LSC-8BHC:  Standard hook, thread trimmer, horizontal feed.

Description

Seiko LSC-8BV-2

Seiko LSC Series Industrial Walking Foot Cylinder Arm with Synchronized binder Sewing Machine

Specifications:

Model Seiko LSC-8BV-2: High Speed, Single Needle, Compound Feed and Walking Foot, Narrow Cylinder Arm, with synchronized binder Lockstitch Sewing Machine, with reverse.

Comes with quality brinaco stand on castors.

Optional extra quality brinaco Feed Off The Arm / Pedestal Stand.

Also quality Formica table top 105cm x 50cm x 40cm

The number of needles: Single needle

Max. sewing speed…2,000 s.p.m.

Max. stitch length… 1/4″ (6.2 mm)

Clearance under presser foot by pedal 14mm … by hand 8.5mm

Needle bar stroke…33.2mm

Needle(standard)… DPx17 (#22) , 135×17 (#140)

Thread…8 (Standard)

Hook… Standard horizontal axis hook

Amount of lift of walking foot…2.7 – 5.5mm

Thread take-up lever…Slide type

Lubrication… Semi-automatic lubrication

Narrow Cylinder size…46mm diameter

Working space…258 x 110mm

Motor…750W Servo motor.



Additional information

Weight 85000 g
